Autel MaxiCOM MK808BT OBD2 Automotive Scanner

(12 customer reviews)

$691.50

Please select a variation to see estimated shipping cost.
Added to wishlistRemoved from wishlist 0
SKU: 3256801742429098 Category: Vendor: Meeky Store
  • Origin: Mainland China
  • External Testing Certification: ce
  • Hardware Version: Newest
  • Item Length: 9.4inch
  • Special Features: Bluetooth,Wifi
  • Software Version: Newest
  • Item Width: 5.9inch
  • Model Name: MK808BT
  • Item Height: 1.4inch
  • Power: 5W
  • Item Type: Engine Analyzer
  • Item Weight: 2.65kg
  • Voltage: 5V/1.5A
  • Electronic: Yes
  • Material Type: Plastic + ABS
  • Operating System: AndroidTM 4.4.4, KitKat
  • Processor: Cortex-A9 processor(1.6GHz)
  • Memory: 64GB
  • Display: 7-inch LCD capacitive touchscreen with 1024×600 resolution
  • Sensors: Light sensor for brightness auto changing
  • Power: Charges via 5 VDC power supply
  • Battery: 3.7 V/5000 mAh lithium-polymer battery
  • Power Consumption: 600 mA(LCD on with default brightness,Wi-Fi on)@3.7 V
  • Connectivity: Mini USB 2.0, USB2.0, Wi-Fi, HDMI Type A, Micro SD card slot(supports up to 32GB)
  • Operating Temp: 0 to 55°C(32 to 131°F)
  • Storage Temp: -20 to 60°C (-4 to 140°F)
  • 2022 NEW!: Support active test and complete special functions,Compatible with Videoscope and MaxiBAS BT506 to perform Battery Analysis
  • Warranty: 1 Year
  • Software Update: 1 Year Free Software Update
  • Technical Support: Lifetime
  • Type: OBD2 Automotive Scanner
  • Item: Auto Car Code Reader
  • Model: MK808 BT Version Scanner

Read Me:

1. 100% original Autel unactivated device:
We are Authorized Distributor of Autel Brand, 100% Brand New Autel Original Genuine with software update and warranty. If not, Double compensation will be provided!!!

2. Warranty and Update service:
1 Year Warranty and 1 Year Free Software Update for MK808BT. After you receive the scanner, You can Register the machine's S/N serial number on the Autel official website, Then you can get Free Software Update and Warranty service immediately.

3. Multiple languages:
Support 21 Languages:Simplified Chinese, English, Traditional Chinese, Spanish, French, German, Russian, Japanese, Korean, Polish, Portuguese, Swedish, Persian, Turkish, Thai, Vietnamese, Hebrew, Arabic, Indonesian English, Italian, Dutch…
(Please leave the S/N of machine to authorize the language you want after you receive it.)

Autel Scanner MaxiCOM MK808BT Car Diagnostic Scan Tool, Active Test/Bi-Directional Control, 2022 Upgrade of MK808 MX808, Compatible with BT506/MV108, 28+ Service, All Sys Diagnosis, FCA SGW AutoAuth

Autel Scanner MaxiCOM MK808BT:

Autel MK808BT can access all available vehicle modules including but not limited to PCM, ECM, TCM, CTM, EPS, PDM, BCM, TPM, SCCM, RADIO and etc, covering more than 80 American, Asian and European vehicle makes. Supports complete OBD2 function, which is capable of performing all 10 modes of OBD2 tests.

Autel MK808BT with Bluetooth VCI can perform wireless diagnosis, including reading and clearing codes on all vehicle systems and subsystems, showing full live data stream of multiple sensors in graph & text, ECU information, perform active test(bi-directional control), etc.

2022 Newest Functions Add:

Tap Update icon to update the device's system version to V2.62 or above one and download all available vehicle software. Note: If there is not enough storage for downloading update, customer can insert a micro SD card to the device.

1. Active Test function and Special Function

✔️ Active Test function is used for outputting signal to vehicle control unit using the device to control actuator for test, so that it can test whether the actuator works normally, such as Fuel Pumps test, EGR test, etc.

✔️ Special Function generally refers to the initial adaptation, self-learning or some auto detection function with many procedures that the vehicle is performed after maintenance or reset is done or some related component| in electronic control system is replaced, such as Crankshaft Position Sensor Learn.

2. Battery Test work with MaxiBAS BT506 (BT506 need purchasing separately).

✔️ MK808BT can work with Autel BT506 battery tester to perform professional cranking/ charging system test and In-Vehicle & Out-of Vehicle Battery Test, and with over 95% accuracy result with advanced adaptive condutive technology, which is far more accurate than the 50% of market avreage accuracy.

✔️ Autel automotive battery test tool BT506 can test all 6V and 12V 100-2000CCA batteries including the most regular Flooded, AGM, AGM Spiral, EFB and GEL batteries, and compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA standards.

3. Compatible with Autel MV108/MV105 Inspection Camera (MV108/MV105 need purchasing separately):

This is a very pratical and useful functions, which allows you to have a futher wear situation check on your car engine/transmission,etc internal structure, to avoid further damage or avoid potential dangerous driving.

4. Supports FCA "Auto Auth":

No more spending extra cost to buy 12+8 adapter! Now update the device system and vehicle software to the newest version, Autel scanner can access protected FCA vehicles! With an authenticated AutoAuth account, you can access "AutoAuth" gateway for 2018 and newer FCA vehicles(Chrysler/JEEP/Dodge/Fiat) in the US, Canada, and Mexico to perform diagnostics!

Bi-Directional Control(Active Test):

Featuring Bi-Directional control, this Autel intelligent diagnostic tool – Autel automotive scanner MK808, can output the commands to ECUs, read the ECU data and monitor the operation of the actuators. Through active tests, also called actuator tests, this bi-directional diagnostic scanner can precisely locate the car problems, letting you quickly know whether a specific system, component, or subsystem is functioning properly or not.

For example, If a fuel pump is not working and leads to ignition failure, it could be a faulty pump, wiring, relay, or command. By turning the fuel pump on and off via the MK808BT scanner, you can quickly determine whether it’s a wiring, relay, or pump issue without removing any parts.

Here are some other examples of active tests, which help you locate faults in the shortest time, saving time on troubleshooting:

• Cycle the a/c clutch on and off;
• Switch the interior lights on and off;
• Perform an evaporative emissions leak test;
• Active tests for inside mirrors, exterior mirrors (high version only), adaptive headlamp, steering wheel heating, windows, wash/wipe system, horn, reset starter lock, etc.

OE-Level Full Systems Diagnostics:

Utilizing Auto Vin and Auto Scan, Autel MK808BT diagnostic scanner can automatically retrieve the vehicle information and perform a comprehensive scan of all available systems, including but not limited to Engine, Transmission, SRS(Airbag), ABS, Airbag, PCM, ECM, TCM, CTM, etc, getting accurate and in-depth results across all automotive systems.

• Read/EraseCodes – Displays detailed information of DTC records to erase DTC records and other data
• View live data stream in text or graph: Retrieves and displays live data and parameters from the vehicle’s ECU
• ECU information: Retrieve ECU information of the tested control units including unit type, version numbers, and other specifications, etc.
• Freeze frame Data: Freeze error codes at the moment occurs, and you can analyze the error code caused.

28+ Advanced Service:

MK808BT automotive diagnostic tool performs 28+ maintenance services including Oil Reset, EPB Reset, SAS Reset, DPF Regeneration, Battery Registration, Throttle Reset, ABS Bleed, Injector Coding, IMMO keys(add new keys, delete lost keys), Window Door Roof, Headlamp and etc, Meeting common maintenance needs.

• Oil Reset: Turn off the oil light, and reset the service mileage.
• EPB Reset: Reset the brake pads after replacement.
• DPF Regeneration: Clear the blockage in the DPF filter, to meet emission standards.
• ABS Bleed: Cycling the ABS system to bleed the air out of the ABS system before traditional bleeding.
• Injector Coding: Coding the new injector after replacement.
• IMMO Keys: Add new keys, key learning, disable lost keys. (For Asian cars with low-grade IMMO system only)

And Throttle Adaption, Airbag Reset, SAS Calibration, Suspension Calibration, Gear Learning, Sunroof Initialization, Seats Calibration, Language Change, Headlight Matching, A/F Setting, WIN DR Roof, Odometer, CHG Tire Size, Cylinder, Turbocharging, Limit, Trans Adaption, Power Balance, Component Matching, etc.

OBDII Full Functions::

This option presents a quick way to check for DTCs, isolate the cause of an illuminated malfunction indicator lamp (MIL), check monitor status prior to emissions certification testing, verify repairs, and perform a number of other services that are emissions-related. The OBD direct access option is also used for testing OBD II/EOBD compliant vehicles that are not included in the Diagnostics database.

• DTC & FFD
• I/M Readiness
• Live Data
• OBD2 Sensor Monitor
• On-Board Monitor
• Component Test
• Vehicle Information
• Vehicle Status

ABS Brake Auto Bleed:

The ABS/SRS diagnostic function is used to retrieve and clear DTCs, display and save data streams or module information, and perform various function tests on the vehicle’s ABS/SRS systems. What is more, the Auto Bleed function will help get air that is trapped in the ABS actuator module out when bleeding your brake lines.

IMMO Keys for Asian Vehicles:

Add New Key: Add An Extra Key To The Vehicle
Disable the lost vehicle keys.

The IMMO Keys function is designed for Asian vehicles that have low-grade anti-theft systems and NOT intended for AUDI, Benz, BMW, VW which have advanced IMMO systems. If need IMMO functions, please consider Autel IMMO tools, such as IM508/IM608 (Pro).

4 Methods for Vehicle Identification:

1. Auto VIN Scan:
The MaxiCOM diagnostic system features the latest VIN-based Auto VIN Scan function to identify vehicles and scan all the diagnosable ECUs and run diagnostics on the selected system. This function is compatible with 2006 and newer vehicles.

2. Manual VIN Input:

For vehicles not supporting the Auto VIN Scan function, you may
manually enter the vehicle VIN.

3. Automatic Selection:
The Auto VIN Scan can be selected after selecting the test vehicle
manufacturer

4. Manual Selection:
When the vehicle’s VIN is not automatically retrievable through the vehicle's ECU, or the specific VIN is unknown, the vehicle can be manually selected.

Unmatched Vehicle Coverage:

The diagnostic computer tablet boasts unmatched vehicle coverage and is capable of accessing and diagnosing more than 80 American, Asian and European vehicle makes.

MK808BT Auto Scanner supports all OBDII-Compliant vehicles through the 16-PIN DLC to perform all 10 modes of OBD2 tests.

The Autel MaxiCOM Autel MK808BT works well with: Acura, Audi, Benz, Bentley, BMW, Bugatti, Chevrolet, Chrysler, Corolla Gm, Holden, Ford, Honda, Hyundai, Infiniti, Kia, Land Rover, Isuzu, Jaguar, Lexus, Maybach, Mitsubishi, Nissan, Mazda, Mini, Opel, Porsche, Saab, Scion, Smart, Seat, Skoda, Sprinter, Subaru, Vauxhall, Volvo, Suzuki, Toyota, and Volkswagen vehicles, etc.

Useful APPs for Shops and DIYs:

1.Shop Manager: You can well manage the workshop information with 3 available functions within this application: Vehicle History, Workshop Information, and Customer Manager. Intuitively look up the summarized details.

2.Data Manager: In case of any issues while performing diagnostics or services functions, please reproduce the issue and go to Data Manager- Data Logging to upload data log to Autel server and send us the serial number(at the back of the unit) to follow up the case until it's resolved satisfactorily.

3.Remote Desk: You can directly get ad-hoc remote support from Autel via Team Viewer software.

4.Cloud Report Management: Allows you to upload diagnostic reports to Autel Cloud so you can share reports with customers through QR Code/ email/ text message directly, customers can view the reports anytime.

1 Year Free Software Updates:

MK808BT wireless scan tool comes with 12 Months Free Software Updates to keep your scan tool up to date to accommodate the newest cars. You can still use the last update software when it expires. Or you can choose to renew the annual subscription to always keep it up to date.

Advanced Hardware:

● Extraordinarily powerful Cortex-A9 processor (1.5 GHz) processor
● 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display
● Internal reliable 32GB On-board Memory for better performance
● Unique ergonomic design with rubberized outer protection and a rugged internal housing
● Android 4.4.2 KitKat Operating System for fast boot-up and multitasking

MK808BT Package List:

1 x MK808BT Tablet
1 x USB External Power Adapter_test
1 x USB Cable (for charging)
1 x USB Cable (for test)
1 x MaxiVCI Mini
1 x User Manual
1 x Quick Reference Guide
